The Trek Top Fuel 5 Mountain Bike is a nimble alloy trail bike that's ready to hammer up climbs and hold its own on descents – all without breaking the bank.
The Trek Top Fuel 5 Mountain Bike is a nimble alloy trail bike that's ready to hammer up climbs and hold its own on descents – all without breaking the bank.
Trek

Trek Top Fuel 5 Mountain Bike 2025 Matte Mercury

£2,500.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Not happy with your purchase? Send it back to us or return in any of our stores and we will give you a full refund or exchange!

Returns

In the unlikely event that you are dissatisfied with your purchase please feel free to return your goods within 60 days of the purchase date for a full exchange or refund. Any item (excluding food and underwear) can be returned to us for any reason provided it is returned in ‘showroom condition’, with its original packaging, tags and a valid receipt/delivery note.

Simply box up your items for return, include a cover note with the word REFUND or EXCHANGE inside & follow the below steps for safe return to our warehouse; where your return will be processed promptly.

Return Items by Post

It is your responsibility to ensure that the item is returned to us in a safe and secure manner, and in the event of a refund or exchange, in saleable condition (in original packaging and including all warranty, cards, manuals and accessories).

Customers are accountable for return shipping charges.

  1. You should always keep proof of postage and we advise you to use a ‘signed for service’ when returning goods.
  2. Send your package using a recorded delivery method (always keep a copy of your receipt!) to the following address:

Leisure Lakes Bikes Returns,
Unit 1 Osprey Place
Titan Way,
Leyland,
PR26 7EW

Checkout by Amazon Returns

If you used the pay by Amazon option when checking out then please send your package using a recorded delivery method (always keep a copy of your receipt!) with a note inside stating whether you want an exchange (what you want it exchanging for) or refund, to the following address:

Leisure Lakes Bikes Returns,
Unit 1 Osprey Place
Titan Way,
Leyland,
PR26 7EW

Bike & Bulky Item Returns

If you wish to return your bike to us please keep it in the box it arrived in and call us on 01772 644340 and we will arrange a collection.

Please note the following:

  • a) If we have sent you the incorrect bicycle, we will cover the cost of collection and delivery of the correct model.
  • b) If we have delivered the bicycle you ordered, but upon inspection you decide it is not the bike for you, we will charge you £50.00 for the collection.

Please do not ride the bike as a full refund cannot be given if the bike has been used or damaged.

Return Items to a store

Any item (excluding food and underwear) can be returned to any Leisure Lakes Bikes store not just the one you made your purchase at, including those made online. The item must be returned in ‘showroom condition’, with its original packaging, tags and with a valid receipt/delivery note.

Wrong size or you don't like the item?

If returning items that are not suitable for either refund or exchange you are accountable for the delivery cost in returning it to us. You should always keep proof of postage and we advise you to use a ‘signed for service’ when returning goods.

New faulty items/ Wrong Item Received

If you have received items that are faulty or not what you ordered send them back to us (using the steps above) and we will cover the delivery cost of the return if it is within 14 days of delivery. If we have supplied the correct product, it is not faulty or it is outside of the 14 days we can not be liable for your postage charges. You should always keep proof of postage and we advise you to use a ‘signed for service’ when returning goods.

In the event that you have received items that are fault or not what you ordered, please send them back to us as soon as possible. Only in these cases will we cover the cost of the return shipping charges.

Faulty Items

If you have received items that are faulty please send them back to us using the steps above. Please include a covering letter describing the fault and if you would like the item replacing or refunding. Once the item arrives back at our Mail Order Centre you will receive an email notifying you about the progress. Faulty items are then forwarded onto the suppliers to confirm the warranty issue. Please be patient with us as we need to receive this confirmation from the suppliers before we can process your request for a replacement/refund.

When returning the item please use Royal Mail1stClass Recorded* so that you have a tracking reference just in case! If your item arrived faulty we will refund your postage cost. If the item was in full working order at the time of delivery to you, we can not refund your return postage cost.

*In the event that you return a faulty/incorrect item we will refund your postage charge as long as it is 1stClass Recorded or a lesser value service. We do not refund premium services.

Refunds

Refunds will be processed using the same method of payment used for the original purchase. Credit and debit card refunds must be made to the card used for the original transaction, cheque payments will be refunded in cash but due to banking restrictions can only be refunded at least 14 days after the original purchase date. Due to the high incidence of fraud we regret that we are unable to offer any refund without a valid receipt/delivery note.

Refunds will be made for faulty or incorrect items, including any delivery charge incurred by the buyer (excluding ‘Special Delivery’) in the return of the item. If the products you ordered are delivered to you in good condition but you wish to return them for any reason we will refund the full value of the goods excluding any carriage charge upon receipt of your returned goods.

Items won’t be considered lost until after 15 working days of items beingdispatched. Once the 15 working days are up we will issue a refund or replacement.

Not received your order?

If you have not received your order please call us on 01772 644340 and a member of staff can confirm the shipping date. Unfortunately we cannot consider an item to be lost until 15 working days has passed (according to Royal Mail procedure). Once the 15 working days have passed we will be able to issue a full refund or resend your order.

Trek Top Fuel 5 Mountain Bike 2025 Matte Mercury

Season:2025

Brand:Trek

Code:25-46142-GRY

The Trek Top Fuel 5 Mountain Bike is a nimble alloy trail bike that's ready to hammer up climbs and hold its own on descents – all without breaking the bank. It offers 130 mm of front and 120 mm of rear suspension that gives you just enough squish to soak up chatter without draining your power on all-day pedal fests. It comes equipped with a RockShox suspension package and Shimano Deore group set that gives you everything you need to rip in an economical package.

It's right for you if...

You want to dive into a full suspension rig and want a light, yet capable alloy ride to get you there. Cost is an important factor, and you don't mind upgrading some parts over time. You want to ride a variety of trails, from smooth cross-country to more rugged all-mountain and you need a versatile bike that stays efficient on long climbs without sacrificing confidence on descents.

The tech you get

An Alpha Platinum Aluminium frame with a 4-way Mino Link for adjusting geometry and leverage rate. A 130 mm RockShox Recon Silver RL fork with SoloAir spring, Motion Control damper and lockout, plus 120 mm of rear travel with an X-Fusion Pro 2 shock with a 2-position damper. It's topped off with a Shimano Deore 12-speed group set, hydraulic disc brakes, a TranzX dropper post and Tubeless Ready Bontrager Line TLR 30 wheels.

The final word

The Top Fuel 5 Gen 4 is a versatile trail bike that finds the balance between efficiency, capability and budget. Its lightweight alloy frame packs in tons of adjustment, thanks to the 4-way Mino Link, with plenty of internal storage for stashing essentials on the ride. An economical component package is ready to hit the trail now and gives you room for upgrades later.

Trek Top Fuel 5 Mountain Bike Highlights

  • Its lightweight frame and versatile geometry make it the perfect choice for all kinds of rides and all kinds of riders
  • The 4-way Mino Link makes it easy to adjust your geometry or leverage rate for how and where you want to ride
  • Its economical build lets you dive into a full suspension mountain bike without breaking the bank, and it leaves room for upgrades over time
  • The Alpha Platinum Aluminium frame is robust, yet light, and packs in updated internal frame storage for easy access to gear and snacks
  • It's more upgrade-ready than ever, with room for bigger 140 mm forks and longer-stroke shocks for up to 130 mm of rear travel, plus room for extra-long dropper posts
Technical Information
Frame
Alpha Platinum Aluminium, internal storage, tapered head tube, internal guided routing, downtube guard, OCLV Next rocker link, Mino 4 link, ABP, Boost148, 120 mm travel
Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel
Shock
X-Fusion Pro 2, 2-position damper, 185 mm x 50 mm
Max compatible fork travel140 mm
Hub front
Bontrager alloy, 6-bolt, Boost110, 15 mm thru-axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
*Tyre
Size: S
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40"
Size: M, ML, L, XL
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim stripBontrager TLR
Max tyre size
Frame: 29x2.50", Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore M6100, long cage
Crank
Shimano MT512, 30T ring, 55 mm chain line, 170 mm length
Bottom bracketShimano BB-MT501 BSA
CassetteShimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Max. chainring size1x: 34T, min 30T
SaddleBontrager Verse P3, steel rails
*Seatpost
Size: S
TranzX JD-YSI22, 100 mm travel, internal routing, 34.9 mm, 346 mm length
Size: M, ML, L, XL
TranzX JD-YSI22, 170 mm travel, internal routing, 34.9 mm, 497 mm length
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Brake
Shimano MT200 hydraulic disc
Rotor sizeMax brake rotor sizes – Frame: 200 mm, min 180 mm, Fork: see fork manufacturer
BagBontrager BITS Internal Frame Storage Bag
WeightM - 15.90 kg / 35.06 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
Sizing Information
size-table
SizeRider HeightInseam
S

155 - 165 cm

5'1" - 5'5"

74 - 78 cm

29" - 31"

M

165 - 176 cm

5'5" - 5'9"

79 - 83 cm

31" - 33"

ML

173 - 180 cm

5'8" - 5'11"

81 - 86 cm

32" - 34"

L

177 - 188 cm

5'10" - 6'2"

84 - 89 cm

33" - 35"

XL

188 - 195 cm

6'2" - 6'5"

89 - 91 cm

35" - 36"



Sizing table
Frame size letterGeometry positionWheel sizeSeat tubeSeat tube angleEffective seat tube angleHead tube lengthHead angleEffective top tubeBottom bracket dropChainstay lengthOffsetTrailWheelbaseStandoverFrame reachFrame stack
SHigh29"36.069.5°76.5°10.565.9°55.81.043.44.311.1115.070.542.256.6
SLow29"36.069.0°76.0°10.565.5°55.91.643.54.311.5115.170.041.757.0
MHigh29"41.070.5°77.3°10.565.9°58.72.643.44.312.1118.875.545.259.9
MLow29"41.070.0°76.9°10.565.5°58.83.243.54.312.5118.875.044.760.3
MLHigh29"42.070.5°76.6°11.065.9°61.12.643.94.312.1121.075.546.760.4
MLLow29"42.070.0°76.2°11.065.5°61.23.244.04.312.5121.075.046.260.7
LHigh29"43.570.5°76.3°11.565.9°63.02.643.94.312.1122.776.048.260.8
LLow29"43.570.0°75.9°11.565.5°63.13.244.04.312.5122.775.547.761.2
XLHigh29"47.070.5°75.6°13.565.9°67.22.644.44.312.1127.076.551.262.6
XLLow29"47.070.0°75.2°13.565.5°67.33.244.54.312.5127.176.050.763.0
