Frame: FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot
Rear Shock: S1: Fox Float DPS Performance Elite, 3- position adjustment,52.5x210mm, Rx Trail Tune, S2-S6: FOX FLOAT X Performance Elite, LSC, LSR, 2-position lever, 55x210mm
Fork: FOX FLOAT 36 RHYTHM 29, GRIP damper, 44mm offset, 2-position sweep adjust, 15x110mm, 1.5" tapered steerer, 160mm travel
Stem: Alloy Trail Stem, 35mm bar bore
Handlebars: Specialized, 6061 alloy, 6-degree upsweep, 8-degreebacksweep, 30mm rise, 780mm width
Front Brake: SRAM Code RS, 4-piston caliper, hydraulic disc, S1-S3: 200mm, S4-S6: 220mm
Rear Brake: SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm
Rear Derailleur: SRAM GX Eagle, 12-speed
Shift Levers: SRAM GX Eagle, 12-speed
Cassette: SRAM XG-1275, 12-speed, 10-52t
Chain: SRAM NX Eagle, 12-speed
Crankset: Praxis forged M30, custom offset, 160mm
Chainrings: SRAM X-Sync Eagle, 104 BCD, 32T, steel
Rims: Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub: Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Spokes: DT Swiss Industry
Front Tire: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
Rear Tire: Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
Inner Tubes: Standard, Presta Valve
Saddle: Bridge Comp, Hollow Cr-mo rails, 155/143mm
SeatPost: X-Fusion Manic, infinite adjustable, two-bolt head, bottom mountcable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm
Seat Binder: Alloy, 38.6mm
Motor: Specialized Turbo Full Power System 2.2 Motor
UI/Remote: Specialized MasterMind TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
Battery: Specialized M3-700, Integrated battery, 700Wh
Charger Custom: charger, 42V4A w/ Rosenberger plug
Wiring Harness: Custom Specialized wiring harness
SWAT: SWAT CC steerer tube integrated tool with chain tool and link
GeometryTUBO LEVO | S1 | S2 | S3S | S4 | S5 | S6 |
Stack(mm) | 605 | 617 | 626 | 635 | 644 | 653 |
Reach (mm) | 412 | 432 | 452 | 477 | 502 | 532 |
Headtube angle (deg) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
BB Height (mm) | 352 | 350 | 35 | 350 | 350 | 350 |
BB Drop (mm) | 25 | 27 | 27 | 27 | 27 | 27 |
Trail (mm) | 130 | 130 | 130 | 130 | 130 | 130 |
Fork Length (full) | 557 | 567 | 567 | 567 | 567 | 567 |
Fork Rake/Offset (mm) | 44 | 44 | 44 | 44 | 44 | 44 |
Front Center (mm) | 738 | 760 | 784 | 814 | 843 | 878 |
Chainstay Length (mm) | 442 | 442 | 442 | 442 | 442 | 442 |
Wheelbase (mm) | 1179 | 1200 | 1225 | 1255 | 1284 | 1318 |
Bike Standover Height (mm) | 752 | 776 | 783 | 787 | 788 | 790 |
Seat Tube Length (mm) | 380 | 390 | 405 | 425 | 445 | 465 |
Seat Tube Angle (°) | 78 | 77.2 | 76.7 | 76.2 | 76.2 | 76.2 |
