Frame: Specialized M5 premium alloy, headset adjust, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing
Rear Shock: S1: FOX DPS Performance Series, 3-position lever, rebound adjust, 52.5x210mm, S2-S6: FOX FLOAT X Performance, LSR, 2-position lever, 55x210mm
Fork: Fox Rhythm 36, S1: 150mm travel, S2-S6: 160mm travel
Stem: Alloy Trail Stem, 35mm bar bore
Handlebars: Alloy, 35mm diameter, 780mm width, 8-degree backsweep,6-degree upsweep
Front Brake: SRAM Code R, 4-piston caliper, S1-S3: 200mm, S4-S6: 220mm
Rear Brake: SRAM Code R, 4-piston caliper, hydraulic disc, 200mm
Rear Derailleur: SRAM GX Eagle, 12-speed
Shift Levers: SRAM GX Eagle, 12-speed
Cassette: SRAM XG-1275, 12-speed, 10-52t
Chain: SRAM NX Eagle, 12-speed
Crankset: Praxis forged M30, custom offset, 160mm
Chainrings: SRAM X-Sync Eagle, 104 BCD, 32T, steel
Rims: Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub: Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Spokes: DT Swiss Industry
Front Tire: Butcher, GRID TRAIL, GRIPTON® T9 compound, 2BR, 29x2.6"
Rear Tire: Eliminator, GRID TRAIL, GRIPTON® T7 compound, 2BR, 27.5x2.6"
Inner Tubes: Standard, Presta Valve
Saddle: Bridge Comp, Hollow Cr-mo rails, 155/143mm
SeatPost: X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm
Seat Binder: Alloy, 38.6mm
Motor: Specialized Turbo Full Power System 2.2 Motor
UI/Remote: Specialized TCU, 10-LED State of charge, 3-LED Ride Mode
display, ANT+/Bluetooth®, w/Handlebar remote
Battery: Specialized M3-700, Integrated battery, 700Wh
Charger Custom: charger, 42V4A w/ Rosenberger plug
Wiring Harness; Custom Specialized wiring harness
GeometryTUBO LEVO ALLOY | S1 | S2 | S3S | S4 | S5 | S6 |
Stack(mm) | 605 | 617 | 626 | 635 | 644 | 653 |
Reach (mm) | 412 | 432 | 452 | 477 | 502 | 532 |
Headtube angle (deg) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
BB Height (mm) | 352 | 350 | 35 | 350 | 350 | 350 |
BB Drop (mm) | 25 | 27 | 27 | 27 | 27 | 27 |
Trail (mm) | 130 | 130 | 130 | 130 | 130 | 130 |
Fork Length (full) | 557 | 567 | 567 | 567 | 567 | 567 |
Fork Rake/Offset (mm) | 44 | 44 | 44 | 44 | 44 | 44 |
Front Center (mm) | 738 | 760 | 784 | 814 | 843 | 878 |
Chainstay Length (mm) | 442 | 442 | 442 | 442 | 442 | 442 |
Wheelbase (mm) | 1179 | 1200 | 1225 | 1255 | 1284 | 1318 |
Bike Standover Height (mm) | 752 | 776 | 783 | 787 | 788 | 790 |
Seat Tube Length (mm) | 380 | 390 | 405 | 425 | 445 | 465 |
Seat Tube Angle (°) | 78 | 77.2 | 76.7 | 76.2 | 76.2 | 76.2 |
