Frame: Specialized M5 premium alloy, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing
Rear Shock: RockShox Deluxe Select R, rebound adjust, S1: 52.5x210mm, S2-S6: 55x210mm
Fork Rock: Shox 35 Silver, 35mm stanchion, Turnkey damper, S1:150mm travel, S2-S6: 160mm travel
Stem: Alloy Trail Stem, 35mm bar bore
Handlebars: Alloy, 35mm diameter, 780mm width, 8-degree backsweep,6-degree upsweep
Front Brake: SRAM Guide RE, S1-S3: 200mm, S4-S6: 220mm
Rear Brake: SRAM Guide RE, 200mm
Rear Derailleur: SRAM SX Eagle, 12-speed
Shift Levers: SRAM SL SX Eagle, 12-speed
Cassette: SRAM NX Eagle PG-1230, 12-speed, 11-50t
Chain: SRAM NX Eagle, 12-speed
Crankset: Praxis forged M30, custom offset, 160mm
Chainrings: SRAM X-Sync Eagle, 104 BCD, 32T, steel
Rims: Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 32h
Rear Hub: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h Spokes DT Swiss Industry
Front Tire: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2BlissReady, 29x2.6"
Rear Tire: Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2BlissReady, 27.5x2.6"
Inner Tubes: Standard, Presta Valve
Saddle: Body Geometry Bridge Saddle, steel rails
SeatPost: TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6- 200mm
Seat Binder: Alloy, 38.6
Motor: Specialized Turbo Full Power System 2.2 Motor
UI/Remote: Specialized TCU, 10-LED State of charge, 3-LED Ride Mode
display, ANT+/Bluetooth®, w/Handlebar remote
Battery: Specialized M3-500, Integrated battery, 500Wh
Charger: Custom charger, 42V4A w/ Rosenberger plug
Wiring Harness: Custom Specialized wiring harness
GeometryTUBO LEVO ALLOY | S1 | S2 | S3S | S4 | S5 | S6 |
Stack(mm) | 605 | 617 | 626 | 635 | 644 | 653 |
Reach (mm) | 412 | 432 | 452 | 477 | 502 | 532 |
Headtube angle (deg) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
BB Height (mm) | 352 | 350 | 35 | 350 | 350 | 350 |
BB Drop (mm) | 25 | 27 | 27 | 27 | 27 | 27 |
Trail (mm) | 130 | 130 | 130 | 130 | 130 | 130 |
Fork Length (full) | 557 | 567 | 567 | 567 | 567 | 567 |
Fork Rake/Offset (mm) | 44 | 44 | 44 | 44 | 44 | 44 |
Front Center (mm) | 738 | 760 | 784 | 814 | 843 | 878 |
Chainstay Length (mm) | 442 | 442 | 442 | 442 | 442 | 442 |
Wheelbase (mm) | 1179 | 1200 | 1225 | 1255 | 1284 | 1318 |
Bike Standover Height (mm) | 752 | 776 | 783 | 787 | 788 | 790 |
Seat Tube Length (mm) | 380 | 390 | 405 | 425 | 445 | 465 |
Seat Tube Angle (°) | 78 | 77.2 | 76.7 | 76.2 | 76.2 | 76.2 |
