ENGINE Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
DISPLAY Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY InTube, 630 Wh
FRAME FAMILY Haibike, AllMtn Yamaha i630, Aluminium
FORK RockShox, 35 Silver, Air, Travel= 160 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
DAMPER SR Suntour, Edge LO-R8, Air, Trunnion Mount M8x25
CRANK ARM Haibike Components, The Crank +, Aluminium
BRAKE (FRONT) Tektro, Orion M745 , 203 mm, 4-piston disc brake
BRAKE (REAR) Tektro, Orion M745 , 180 mm, 4-piston disc brake
TUBE Presta valve
RIM Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
CLAMPING RING Internal hexagon, 34.9 mm
REAR DERAILLEUR Shimano, Deore M5100
SHIFT LEVER Shimano, Deore M5100, Trigger switch, 11 Speed
BOTTOM BRACKET Integrated in the motor
SPROCKET Shimano, M5100, 11 - 51 teeth
CHAIN KMC, X11e
CHAINRING Steel, 38 teeth
BRAKE LEVER Tektro, Orion M745, Aluminium
BRAKE DISC (FRONT) Tektro, TR203
BRAKE DISC (REAR) Tektro, TR180
TYRE Continental, Trail King, 60-622, 29" x 2.4"
FRONT WHEEL HUB Haibike Components, TheHub ++, 6-bolt standard
REAR WHEEL HUB Haibike Components, TheHub ++ Steckachse 12x148, 6-bolt standard
SPOKES Sapim, Leader, Black
HANDLEBAR Haibike Components, TheBar +++ Gravity , 780 mm
GRIPS Haibike, MTB grips
STEM Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 7.0 °
HEADSET Feimin, A-Head Tapered, Ball bearing
SADDLE Selle Royal Vivo 1216HRN
SEAT POST Haibike Components, TheSeatpost ++, Aluminium, 31.6 mm
PEDALS Freeridepedal , Aluminium, with Reflector,
PERMITTED TOTAL WEIGHT 120.0 kg
TYRE (REAR) Continental, Trail King, 65-584, 27.5" x 2.6"
RIM (REAR) Rodi, Tryp 35, Aluminium, with eyelets, hollow rim
